Hardware Recommendations for SOLIDWORKS

system requirements and current recommendations

Not all system configurations are right for every engineer, so drilling into what tasks and components engineers are using is important. That’s why GoEngineer has teamed up with DELL to provide specialized solutions for CAD product designers and engineers for everything from SOLIDWORKS PDM, through SOLIDWORKS Professional, SOLIDWORKS Visualize, and SOLIDWORKS Simulation packages.   Shop the GoEngineer Dell Expert Network

Get an additional  5% OFF your DELL purchase

Computer Workstation Setups that run SOLIDWORKS Simulation

System Requirements

Basic System

Processor:       3.3GHz or faster, Intel® Core i5, i7 or equivalent AMD®
Operating System      : Windows® 10
Memory:        8GB or more is required
Hard Drive:       Standard or Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:   NVIDIA® Quadro® P2200

  • System for simple parts, small assemblies (200 or fewer components), and drawings.
  • This system will support part and assembly simulations including linear statics, thermal, frequency, fatigue, and optimization. Gap and contact simulations will run on small assemblies that contain simple components.
  • This system will also support simple flow simulations.
Intermediate System

Processor:       3.3GHz or faster, Intel® Core i7, Xeon or equivalent AMD®
Operating System      : Windows® 10
Memory      :        16GB or more as required
Hard Drive:        Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:   NVIDIA® Quadro® RTX 4000

  • System for complex parts with advanced shapes, large patterns, shells, 200+ features.
  • This system is also for assemblies containing 200-1000 components and drawings.
  • This system will support part and assembly simulations including non-linear, dynamics, random vibrations along with moderate gaps and contacts.
  • This system will also support moderate flow simulations.
Advanced System

Processor:       3.3GHz or faster, Intel® Core i7, Xeon or equivalent AMD®
Operating System      : Windows® 10
Memory:        32GB or more as required
Hard Drive:        Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:   NVIDIA® Quadro® RTX 5000, RTX 6000, RTX 8000

  • System for very complex parts with advanced surfacing features or hybrid modeling.
  • This system is also for assemblies containing 1000 – 200,000 components.
  • This system will support large complex analysis and large flow simulations.



Minimum hardware requirements for SOLIDWORKS 2021:

The minimum requirements can be found on the SOLIDWORKS System Requirements website.

Video:

A recommended OpenGL workstation graphics card and driver.
For a listing of recommended graphics cards and driver combinations visit the SOLIDWORKS System/Graphics Card Requirements Website.
https://www.solidworks.com/support/hardware-certification

CPU:

Intel® or AMD® with SSE2 support. A 64-bit operating system required.
SOLIDWORKS can be made to run on Apple Mac® based machines running under Parallels or BootCamp.  It is not a recommended hardware configuration.
http://www.solidworks.com/sw/support/11168_ENU_HTML.htm
NOTE:    Non-server products are only supported in the Parallels environment.
eDrawings® is supported on Apple Macintosh®-based machines.

Other:

Mouse or another pointing device.
DVD drive or broadband internet connection
Microsoft Excel 2016, or 2019
Internet Explorer version 11 or Microsoft Edge
Anti-Virus ( http://www.solidworks.com/sw/support/AntiVirus_SW.html )

Network:

SOLIDWORKS is tested only with Microsoft’s Windows Networking and Active Directory network environments.
Novell networks and non-Windows based network storage devices are not supported.

OS:

Window 10®  (SOLIDWORKS 2015 SP5+)          Note: Windows Home, Small Business, and To Go editions are not supported.

SNL Server Requirements:

Windows 10®
Windows Server 2016®, 2019®
Virtual servers are supported for SNL only for the ones listed here (   http://www.solidworks.com/sw/support/11168_ENU_HTML.htm   ).

PDM Professional, Standard:

The system requirements for PDM can be found here,   https://www.solidworks.com/sw/support/SystemRequirements.html

End of Life Product Info

http://www.solidworks.com/sw/support/solidworks-support.htm?tabshow=2



Basic System

Processor:    3.3GHz or faster, Intel® Core i5, i7 or equivalent AMD®
Operating System   : Windows® 10 and 7   (2020 was the last year for Windows 7 support)
Memory:     8GB or more is required
Hard Drive:    Standard or Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:  NVIDIA® Quadro® P2200

  • System for simple parts, small assemblies (200 or fewer components), and drawings.
  • This system will support part and assembly simulations including linear statics, thermal, frequency, fatigue, and optimization. Gap and contact simulations will run on small assemblies that contain simple components.
  • This system will also support simple flow simulations.
Intermediate System

Processor:    3.3GHz or faster, Intel® Core i7, Xeon or equivalent AMD®
Operating System   : Windows® 10 and 7   (2020 was the last year for Windows 7 support)
Memory   :     16GB or more as required
Hard Drive:     Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:   NVIDIA® Quadro®RTX 4000

  • System for complex parts with advanced shapes, large patterns, shells, 200+ features.
  • This system is also for assemblies containing 200-1000 components and drawings.
  • This system will support part and assembly simulations including non-linear, dynamics, random vibrations along with moderate gaps and contacts.
  • This system will also support moderate flow simulations.
Advanced System

Processor:    3.3GHz or faster, Intel® Core i7, Xeon or equivalent AMD®
Operating System   : Windows® 10 and 7   (2020 was the last year for Windows 7 support)
Memory:     32GB or more as required
Hard Drive:     Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards: NVIDIA® Quadro® RTX 5000, RTX 6000, RTX 8000

  • System for very complex parts with advanced surfacing features or hybrid modeling.
  • This system is also for assemblies containing 1000 – 200,000 components.
  • This system will support large complex analysis and large flow simulations.



Minimum hardware requirements for SOLIDWORKS 2020:

The minimum requirements can be found on the    SOLIDWORKS System Requirements website   .

Video:

A recommended OpenGL workstation graphics card and driver.
For a listing of recommended graphics cards and driver combinations visit the SOLIDWORKS System/Graphics Card Requirements Website.
https://www.solidworks.com/support/hardware-certification

CPU:

Intel® or AMD® with SSE2 support. A 64-bit operating system required.
SOLIDWORKS can be made to run on Apple Mac® based machines running under Parallels or BootCamp.  It is not a recommended hardware configuration.
http://www.solidworks.com/sw/support/11168_ENU_HTML.htm
NOTE:   Non-server products are only supported in the Parallels environment.
eDrawings® is supported on Apple Macintosh®-based machines.

Other:

Mouse or another pointing device.
DVD drive or broadband internet connection
Microsoft Excel 2013, 2016, or 2019
Internet Explorer version 11 or Microsoft Edge
Anti-Virus ( http://www.solidworks.com/sw/support/AntiVirus_SW.html   )

Network:

SOLIDWORKS is tested only with Microsoft’s Windows Networking and Active Directory network environments.
Novell networks and non-Windows based network storage devices are not supported.

OS:

Window 10®  (SOLIDWORKS 2015 SP5+)      Note: Windows Home, Small Business, and To Go editions are not supported.
Windows 7® 64-bit professional or greater editions only      (2020 is the last year for Windows 7 support)

SNL Server Requirements:

Windows 7®, 10®
Windows Server 2016®, 2019®
Virtual servers are supported for SNL only for the ones listed here (   http://www.solidworks.com/sw/support/11168_ENU_HTML.htm ).

PDM Professional, Standard:

The system requirements for PDM can be found here,      https://www.solidworks.com/sw/support/SystemRequirements.html

End of Life Product Info

http://www.solidworks.com/sw/support/solidworks-support.htm?tabshow=2



Minimum System Requirements

Processor:  3.3GHz or faster, Intel® Core i5, i7 or equivalent AMD®
Operating System : Windows® 10 or 7 x64
Memory:   8GB or more recommended
Hard Drive:  Standard or Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:   NVIDIA® Quadro®   P600, P1000 series

  • System for simple parts, small assemblies (200 or fewer components), and drawings.
  • This system will support part and assembly simulations including linear statics, thermal, frequency, fatigue, and optimization. Gap and contact simulations will run on small assemblies that contain simple components.
  • This system will also support simple flow simulations.
  • Approximate Costs: Laptop – $1600 | Desktop – $1400
Basic System

Processor:  3.3GHz or faster, Intel® Core i7, Xeon or equivalent AMD®
Operating System : Windows® 10 or 7 x64
Memory :   8-16GB or more as required
Hard Drive:   Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards:   NVIDIA® Quadro®   P2000 series

  • System for complex parts with advanced shapes, large patterns, shells, 200+ features.
  • This system is also for assemblies containing 200-1000 components and drawings.
  • This system will support part and assembly simulations including non-linear, dynamics, random vibrations along with moderate gaps and contacts.
  • This system will also support moderate flow simulations.
  • Approximate Costs: Laptop – $2100 | Desktop – $1800
Advanced System

Processor:  3.3GHz or faster, Intel® Core i7, Xeon or equivalent AMD®
Operating System : Windows® 10 or 7 x64
Memory:   16-32GB or more as required
Hard Drive:   Solid State Drive (SSD) > 250GB, keeping 10% drive capacity free space
Graphics Cards: NVIDIA® Quadro®   P3000 P4000 series

  • System for very complex parts with advanced surfacing features or hybrid modeling.
  • This system is also for assemblies containing 1000 – 200,000 components.
  • This system will support large complex analysis and large flow simulations.
  • Approximate Costs: Laptop – $3000 | Desktop – $2500



Minimum hardware requirements for SOLIDWORKS 2019:

The minimum requirements can be found on the  SOLIDWORKS System Requirements website .

Video:

A certified OpenGL workstation graphics card and driver.
For a listing of tested and certified graphics cards and driver, combinations visit the SOLIDWORKS System/Graphics Card Requirements Website.
http://www.solidworks.com/sw/support/videocardtesting.html

CPU:

Intel® or AMD® with SSE2 support. A 64-bit operating system required.
SOLIDWORKS is supported on Apple Mac® based machines running under Parallels.
http://www.solidworks.com/sw/support/11168_ENU_HTML.htm
NOTE:   Non-server products are only supported in the Parallels environment.
eDrawings® is supported on Apple Macintosh®-based machines.

Other:

Mouse or another pointing device.
DVD drive or broadband internet connection
Microsoft Excel 2010, 2013, or 2016
Internet Explorer version 8 or higher
Anti-Virus ( http://www.solidworks.com/sw/support/AntiVirus_SW.html )

Network:

SOLIDWORKS is tested only with Microsoft’s Windows Networking and Active Directory network environments.
Novell networks and non-Windows based network storage devices are not supported.

OS:

Window 10®  (SOLIDWORKS 2015 SP5+)   Note: Windows Home, Small Business, and To Go editions are not supported.
Windows 7® 64-bit professional or greater editions only

SNL Server Requirements:

Windows 7®, 10®
Windows Server 2012® R2, 2016®
Virtual servers are supported for SNL only for the ones listed here ( http://www.solidworks.com/sw/support/11168_ENU_HTML.htm ).

PDM Professional, Standard:

The system requirements for PDM can be found here,   http://www.solidworks.com/sw/support/PDMSystemRequirements.html .

End of Life Product Info

http://www.solidworks.com/sw/support/solidworks-support.htm?tabshow=2

System Samples

Minimum System from Dell®

SOLIDWORKS 2019 Hardware Reccomendations Precision 7520 Summary

Figure 1 – Minimum System Sample from Dell®

Basic System from Dell®

SOLIDWORKS 2019 Hardware Recommendations Dell 7520 Summary

Figure 2 – Basic System Sample from Dell®

Advanced System from Dell®

Hardware Recommendations SOLIDWORKS 2019 Dell Precision 7720

Figure 3 – Advanced System Sample from Dell®

SOLIDWORKS Services:

Utilize GoEngineer’s Award Winning Support & Training for SOLIDWORKS

Award Winning Technical Support

GoEngineer's extensive SOLIDWORKS technical knowledge and world class support can help you succeed with SOLIDWORKS. Our award-winning team is ready to help you with any task you may have. Using state-of-art remote assistant technology software allows our team to solve most issues within one session. Reach out and see why GoEngineer is the #1 reseller of SOLIDWORKS and Stratasys systems in the world!

  • 125+Certified Technical Specialists
  • Email, Phone and Chat Support Available
  • 98% Exceptional Customer Service Rating

LEARN MORE

PROFESSIONAL SOLIDWORKS TRAINING

GoEngineer offers online and classroom professional SOLIDWORKS training for organizations and individuals. All our instructors are SOLIDWORKS certified and teach thousands of students each year world wide. The curriculum is very diverse with numerous certified SOLIDWORKS courses to choose from. Each student will receive a Course Completion Certificate and preparation materials for SOLIDWORKS certification.

  • Increase Your Earning Potential
  • Led by Certified SOLIDWORKS Instructors
  • Smaller Classes with Focused Attention

LEARN MORE

Additional Resources

Take Advantage of GoEngineer’s Extensive Knowledge Base and Resources

GoEngineer Knowledge Base and website search

Find a Solution

Our robust Knowledge Base contains over 12,000 resources to help answer your product design questions. From basic CAD questions to in-depth guides and tutorials, find your solution here. Find a Solution

Get Certified Professional SOLIDWORKS Training at GoEngineer

PROFESSIONAL TRAINING

Improve your skills with professional training and certifications in SOLIDWORKS, CAM, 3D Printing, and 3D Scanning offered four ways: self-paced, online, on-site, or in-classroom. Certified Training Courses

GoEngineer blog page

BLOG

#1 Technical Resource Worldwide - Right at your fingertips. Search or browse through hundreds of SOLIDWORKS tips & tricks, additive manufacturing product developments, announcements, how-to guides, and tutorials. Blog

GoEngineer YouTube Channel

YouTube Channel

Our YouTube channel hosts hundreds of educational tutorials, product demonstrations, recorded webinars, and best practices for all of our products and services. GoEngineer's YouTube Channel

Order 3D printing materials and consumables from GoEngineer

ONLINE STORE

Order 3D printing materials and consumables, enroll in SOLIDWORKS training classes, and buy official GoEngineer gear directly from our online store. Online Store

Free SOLIDWORKS tools offered from GoEngineer

FREE SOLIDWORKS Tools

Enjoy this collection of small ‘macros’ that were tailored to help our customers. These free SOLIDWORKS tools are for you to use, review, and modify. SOLIDWORKS Automation Tools

Webinars offered by GoEngineer

WEBINARS

Our engineering webinars are hosted by some of the top experts in the industry. They are always recorded, always free, and always offer a live Q&A. WEBINARS

3D design and part printing services available at GoEngineer

3D Printing Services

Need to 3D print a part? Our Additive Manufacturing experts will 3D print your part and deliver it to you using the latest technology on one of our professional FDM, PolyJet, SL, or Metal 3D printers. 3D Printing Services
